บ้าน ผลิตภัณฑ์เครื่อง ECG 12 ช่อง

Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS

สนทนาออนไลน์ตอนนี้ฉัน
ได้รับการรับรอง
อย่างดี เครื่อง ECG แบบใช้มือถือ สำหรับการขาย
อย่างดี เครื่อง ECG แบบใช้มือถือ สำหรับการขาย
คุณภาพดี บริการดี

—— Dr.Alam จากอียิปต์

ผลิตภัณฑ์ที่สมบูรณ์แบบ เล็กและชาญฉลาด!

—— Mr.Yann จากฝรั่งเศส

Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS

Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS
Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS

ภาพใหญ่ :  Portable Professional 12 Channel ECG Machine CE / ISO Resting ECG For IOS ราคาถูกที่สุด

รายละเอียดสินค้า:
Place of Origin: China(Mainland)
ชื่อแบรนด์: V&H
ได้รับการรับรอง: CE & ISO
Model Number: iCV200BLE
การชำระเงิน:
Minimum Order Quantity: 1 set/sets
Packaging Details: standard package
Delivery Time: 7 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 50 sets per week
รายละเอียดสินค้า
Product: Portable professional 12 channel resting ECG for iOS with CE&ISO Type: Resting
Transfer Way: Bluetooth Model No.: iCV200BLE
Color: White Function: Automactically monitor and analysis ECG
Resolution: 0.4 µV Common Mode Rejection: > 110 dB
แสงสูง:

wireless ecg machine

,

cardiac monitoring equipment

Portable professional 12 channel resting ECG for iOS with CE&ISO



iCV200-BLE ecg 12 channel device



CARDIO VIEW iCV200-BLE is a PC-ECG system for doctors and clinics with plans to make multi-function electrocardiograph analysis, including 12-lead Resting ECG, Vector ECG (VCG) and Ventricular Late Potential (VLP).The system automatically stores, analyzes, averages, displays and prints the recorded ECG,VCG and VLP data. In the Windows XP environment, different reports can be viewed on-screen and printed in numerous formats on most Windows compatible printers. By means of regular updating of software,CV-200+ remains state-of-the-art both now and in the future. With the optical isolating ECG signal sampling recorder connected to PC USB interface,iCV200-BLE guarantees high quality ECG data acquisition, user-friendly environment and 100% safety for the patient.





Advantages:

  1. The first professional elsctrocardiogram (ECG) product developed on android portable device.
  2. High-definition ECG display thanks to its Apple high resolution screen and anti-aliased algorithm.
  3. Automatic measurements and interpretations.
  4. Bluetooth communication



ECG Recorder Specifications



Sampling Rate

A/D:24K SPS/Ch

Recording:1K SPS/Ch

Quantization Precision

A/D:24 Bits

Recording:16 Bits

Common Mode Rejection >110dB
Resolution 0.4uV
Input Impedance >20M
Frequency Response 0.05-250Hz(±3bB)
Time Constant >3.2Sec
Maximum Electrode Potential ±300mV DC
Dynamic Range ±15mV
Power 2xAA Batteries
Communication WIFI(ipad,iphone)Blue Tooth(Android)
Defibrillation Project  Build-in
