บ้าน ผลิตภัณฑ์เครื่อง ECG มือถือ

Mobile 12-lead Resting ECG Machine With Multi Function Software

สนทนาออนไลน์ตอนนี้ฉัน
ได้รับการรับรอง
อย่างดี เครื่อง ECG แบบใช้มือถือ สำหรับการขาย
อย่างดี เครื่อง ECG แบบใช้มือถือ สำหรับการขาย
คุณภาพดี บริการดี

—— Dr.Alam จากอียิปต์

ผลิตภัณฑ์ที่สมบูรณ์แบบ เล็กและชาญฉลาด!

—— Mr.Yann จากฝรั่งเศส

Mobile 12-lead Resting ECG Machine With Multi Function Software

Mobile 12-lead Resting ECG Machine With Multi Function Software
Mobile 12-lead Resting ECG Machine With Multi Function Software Mobile 12-lead Resting ECG Machine With Multi Function Software Mobile 12-lead Resting ECG Machine With Multi Function Software

ภาพใหญ่ :  Mobile 12-lead Resting ECG Machine With Multi Function Software ราคาถูกที่สุด

รายละเอียดสินค้า:
Place of Origin: Beijing,China(Mainland)
ชื่อแบรนด์: V & H
ได้รับการรับรอง: CE&ISO
Model Number: CV-200+
การชำระเงิน:
Minimum Order Quantity: 1 Unit
Packaging Details: Standard Package:25cm*20cm*13cm
Delivery Time: 5-8 Work days
Payment Terms: Western Union, T/T, PayPal
Supply Ability: 50 Units Per Week
รายละเอียดสินค้า
Product: Cheap Mobile 12-lead Resting ECG Machine With Multi Function Software Type: Resting
Function: ECG Work Station,Vector ECG Cable: 12-Lead Patient Cable
Color: White Interface: USB
แสงสูง:

ECG monitoring device

,

ECG Workstation

Cheap Mobile 12-lead Resting ECG Machine With Multi Function Software



CV-200+ Rest ECG,VCG and VLP



CARDIO VIEW CV-200 is a PC-ECG system for doctors and clinics with plans to make multi-function electrocardiograph analysis, including 12-lead Resting ECG, Vector ECG (VCG) and Ventricular Late Potential (VLP).The system automatically stores, analyzes, averages, displays and prints the recorded ECG,VCG and VLP data.



In the Windows XP environment, different reports can be viewed on screen and printed in numerous formats on most Windows compatible printers. By means of regular updating of software,CV-200 remains state-of-the-art both now and in the future. With the optical isolating ECG signal sampling recorder connected to PC USB interface,CV-200 guarantees high quality ECG data acquisition, user friendly environment and 100% safety for the patient.



Specification



VH- CV200+ ECG work station specification
Sampling 1000 S/S/Ch,12 bits, Simultaneously 12 Leads Recording
Digital Resolution 2µV
Frequency Response 0.05-250Hz(+3dB)
Common Mode Rejection >90dB
Input Impedance >10 M
Time Constant 3.2 Sec
Maximum Electrode Potential +300mV DC
Dynamic Range +10mV
Isolate Voltage 4000V
Current Leek <10µA
Patient Cable Standard 10-wire,15-Pin D Connector
PC Interface USB Connector
Dimensions 14912226 mm(5.94.81.0 in.)



Minimum Computer System Requirements:



  • Pentium III Processor
  • 128MB RAM
  • 20G HD
  • Windows XP Operating System
  • VGA Compatible Display
  • Windows XP Compatible Laser or Inkjet Printer

Mobile 12-lead Resting ECG Machine With Multi Function Software

Mobile 12-lead Resting ECG Machine With Multi Function Software

About us



Vales and Hills Biomedical Tech. Ltd. (V&H), located on BDA International Park, BEIJING, has been one of the leading developers of PC based ECG technology for years. V&H keeps giving great resources to approach the edge that comes with the idea of sophisticated simplicity in products design and the discipline of management in quality control. V&H is mostly engaged in PC-ECG, ECG Workstation, ECG Stress Test, Digital EEG Series and Ambulatory Blood Pressure Monitor.



V&H's core concept is teamwork on which we have built a truly top-notch team, conceived in collaboration, dedicated to the proposition that we all colleagues working our hearts out toward the goal in rewarding people and society. V&H keeps looking to the future with hope and determination.
